Mikrotik CCR2004-1G-12S+2XS Ethernet Router

Sale price


Ports 10/100/1000 Ethernet ports: 1
SFP+ ports: 12
Number of 25G SFP28 ports: 2
Serial console port: RJ45
Architecture: ARM 64bit
CPU: AL32400
CPU core count: 4
CPU nominal frequency: 1700 MHz
Size of RAM: 4 GB
Storage size: 128 MB
Storage type: NAND
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -20°C to 60°C
Power Mode
Number of AC inputs: 2
AC input range: 100-240
Max power consumption: 49 W
Max power consumption without attachments: 32 W
FAN count: 2
Dimension 443 x 224 x 44 mm
Color White
Warranty 1 year

Features of Mikrotik CCR2004-1G-12S+2XS Ethernet Router

The MikroTik CCR2004-1G-12S+2XS is a high-performance Ethernet router manufactured by MikroTik, a Latvian company that specializes in networking and telecommunications equipment. The CCR2004-1G-12S+2XS is part of MikroTik's Cloud Core Router (CCR) series, designed for demanding enterprise and service provider networks.

Here are some key features and specifications of the MikroTik CCR2004-1G-12S+2XS:

  1. Performance: The router is powered by a quad-core 1.4 GHz ARM CPU and has 4 GB of RAM, providing excellent performance for routing and networking tasks.

  2. Ethernet Ports: It features 1 Gigabit Ethernet port (1G) and 12 SFP+ ports (10G) for high-speed connectivity. Additionally, it has 2 25G SFP28 ports for even faster networking capabilities.

  3. Routing and Switching: The CCR2004-1G-12S+2XS supports advanced routing protocols such as BGP (Border Gateway Protocol) and OSPF (Open Shortest Path First), making it suitable for complex network setups. It can handle extensive routing tables and offers hardware-based switching for optimal performance.

  4. Network Security: The router supports various security features, including firewall, NAT (Network Address Translation), and VPN (Virtual Private Network) functionality, ensuring secure communication and data transmission across the network.

  5. Management and Monitoring: It can be managed using MikroTik's RouterOS software, which provides a user-friendly interface and extensive configuration options. The router also supports various management protocols like SNMP (Simple Network Management Protocol) and can be monitored using tools like The Dude.

  6. Redundancy and High Availability: The CCR2004-1G-12S+2XS supports redundancy features such as VRRP (Virtual Router Redundancy Protocol) and MikroTik's own RouterOS bonding, allowing for seamless failover and improved network uptime.

  7. Power Supply: The router comes with dual redundant power supplies, ensuring reliable operation and minimizing the risk of power-related failures.

  8. Rack Mountable: The device is designed for rack-mounted deployment, fitting into a standard 1U rack space.

The MikroTik CCR2004-1G-12S+2XS is a robust and powerful router suitable for demanding network environments, offering high-speed connectivity, advanced routing capabilities, and strong security features.

What is the price of Mikrotik CCR2004-1G-12S+2XS Ethernet Router in Bangladesh?

The latest price of Mikrotik CCR2004-1G-12S+2XS Ethernet Router in Bangladesh contact with us. To buy this please visit our online store Silicon Computing Ltd. to get the best price in Bangladesh.
