Description
| CPU |
Intel® Xeon® E-2336 6C 12T 2.9GHz, up to 4.8GHz
|
| CPU Architecture | 64-bit x86 |
| Floating Point Unit | Yes |
| Encryption Engine | Yes (AES-NI) |
| System Memory |
32 GB ECC DDR4 (2 x 16 GB)
|
| Maximum Memory | 128GB (4 x 32 GB) |
| Memory Slot | 4 x ECC UDIMM DDR4 |
| Flash Memory |
5GB (Dual boot OS protection)
|
| Drive Bay |
22 (16 x 3.5-inch SATA + 6 x 2.5-inch SATA)
|
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives |
| Hot-swappable | Yes |
| M.2 Slot |
Optional via a QM2 PCIe adapter
|
| SSD Cache Acceleration Support | Yes |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M) |
| 10 Gigabit Ethernet Port |
Optional via a PCIe adapter
|
| Wake on LAN | Yes |
| PCIe | 3 (2 x Gen4 x4 +1 x Gen 4 |
| USB 3.2 Gen 1 port |
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
|
| Form Factor | 3U Rackmount |
| LED Indicators | Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red) |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 131.3 × 482.2 × 550.8 mm |
| Weight (Net) | 15.64 kg |
| Weight (Gross) | 22.08 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
|
| Power Supply Unit | 2 x 550W PSU |
| Power Consumption: Operating Mode, Typical | 228 W |
| Fan |
3 x 60mm + 1 x 80mm, 12VDC
|
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 11000 |
Features of QNAP TS-H2287XU-RP-E2336-32G
The QNAP TS-H2287XU-RP-E2336-32G is a specific model of network-attached storage (NAS) device produced by QNAP Systems, Inc. Here is some information about this particular model:
-
Hardware Specifications:
- Processor: It is equipped with an Intel Xeon E-2336 6-core processor.
- Memory: It has 32 GB of DDR4 ECC RAM, which helps in data integrity and error correction.
- Drive Bays: The NAS supports up to 28 hot-swappable 2.5-inch or 3.5-inch SATA hard drives or SSDs.
- Power Supply: It includes a redundant power supply unit (PSU) for increased reliability.
- Expansion Slots: The TS-H2287XU-RP-E2336-32G has two PCIe Gen3 x8 slots and one PCIe Gen3 x4 slot for adding additional functionality, such as 10GbE or Thunderbolt connectivity.
-
Software Features:
- Operating System: It runs on QNAP's QTS operating system, which provides a range of features and applications for managing and accessing data.
- Data Protection: The NAS supports RAID configurations for data redundancy and protection, including RAID 0, 1, 5, 6, 10, 50, 60, and JBOD.
- Virtualization: It supports virtualization technologies like Virtualization Station and Container Station, allowing you to run virtual machines and containerized applications.
- Data Backup: The device offers various backup options, including scheduled backups, cloud backups, and remote replication to other QNAP NAS devices.
- High Availability: It supports high availability (HA) configurations, allowing for system redundancy and failover protection.
-
Connectivity and Networking:
- Networking: It features four Gigabit Ethernet ports for network connectivity. Depending on the specific model variant, it might also offer built-in 10GbE or 25GbE ports for faster network speeds.
- USB and Thunderbolt: The NAS includes multiple USB 3.2 Gen 2 and USB 3.2 Gen 1 ports for connecting external devices. Some models also provide Thunderbolt 3 ports for high-speed data transfer.
What is the price of QNAP TS-H2287XU-RP-E2336-32G in Bangladesh?
To know the latest price of QNAP TS-H2287XU-RP-E2336-32G in bd contact with us .To buy this please visit our online store Silicon Computing Ltd. to get the best price in Bd.
