QNAP TS-H2287XU-RP-E2336-32G

Sale price
Contact us


Intel® Xeon® E-2336 6C 12T 2.9GHz, up to 4.8GHz
CPU Architecture 64-bit x86
Floating Point Unit Yes
Encryption Engine Yes (AES-NI)
System Memory
32 GB ECC DDR4 (2 x 16 GB)
Maximum Memory 128GB (4 x 32 GB)
Memory Slot 4 x ECC UDIMM DDR4
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
22 (16 x 3.5-inch SATA + 6 x 2.5-inch SATA)
Drive Compatibility
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch bays:
2.5-inch SATA solid state drives
Hot-swappable Yes
M.2 Slot
Optional via a QM2 PCIe adapter
SSD Cache Acceleration Support Yes
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 (2.5G/1G/100M)
10 Gigabit Ethernet Port
Optional via a PCIe adapter
Wake on LAN Yes
PCIe 3 (2 x Gen4 x4 +1 x Gen 4
USB 3.2 Gen 1 port
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
Form Factor 3U Rackmount
LED Indicators Status (Green/Red)
LAN (Green)
USB (Blue)
HDD status (Green/Red)
Buttons Power, Reset
Dimensions (HxWxD) 131.3 × 482.2 × 550.8 mm
Weight (Net) 15.64 kg
Weight (Gross) 22.08 kg
Operating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 2 x 550W PSU
Power Consumption: Operating Mode, Typical 228 W
3 x 60mm + 1 x 80mm, 12VDC
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 11000

Features of QNAP TS-H2287XU-RP-E2336-32G

The QNAP TS-H2287XU-RP-E2336-32G is a specific model of network-attached storage (NAS) device produced by QNAP Systems, Inc. Here is some information about this particular model:

  1. Hardware Specifications:

    • Processor: It is equipped with an Intel Xeon E-2336 6-core processor.
    • Memory: It has 32 GB of DDR4 ECC RAM, which helps in data integrity and error correction.
    • Drive Bays: The NAS supports up to 28 hot-swappable 2.5-inch or 3.5-inch SATA hard drives or SSDs.
    • Power Supply: It includes a redundant power supply unit (PSU) for increased reliability.
    • Expansion Slots: The TS-H2287XU-RP-E2336-32G has two PCIe Gen3 x8 slots and one PCIe Gen3 x4 slot for adding additional functionality, such as 10GbE or Thunderbolt connectivity.
  2. Software Features:

    • Operating System: It runs on QNAP's QTS operating system, which provides a range of features and applications for managing and accessing data.
    • Data Protection: The NAS supports RAID configurations for data redundancy and protection, including RAID 0, 1, 5, 6, 10, 50, 60, and JBOD.
    • Virtualization: It supports virtualization technologies like Virtualization Station and Container Station, allowing you to run virtual machines and containerized applications.
    • Data Backup: The device offers various backup options, including scheduled backups, cloud backups, and remote replication to other QNAP NAS devices.
    • High Availability: It supports high availability (HA) configurations, allowing for system redundancy and failover protection.
  3. Connectivity and Networking:

    • Networking: It features four Gigabit Ethernet ports for network connectivity. Depending on the specific model variant, it might also offer built-in 10GbE or 25GbE ports for faster network speeds.
    • USB and Thunderbolt: The NAS includes multiple USB 3.2 Gen 2 and USB 3.2 Gen 1 ports for connecting external devices. Some models also provide Thunderbolt 3 ports for high-speed data transfer.

What is the price of QNAP TS-H2287XU-RP-E2336-32G in Bangladesh?

To know the latest price of QNAP TS-H2287XU-RP-E2336-32G in bd contact with us .To buy this please visit our online store Silicon Computing Ltd. to get the best price in Bd.
